awan Posted March 23, 2010 Posted March 23, 2010 Hey guys, some of you may have read up on my questions regarding two truck builds (International 4400 and Chevy Kodiak/GMC Topkick)in my self-introduction thread below, so I apologize for the repost but I feel that if there's a dedicated thread, readers might be more likely to see the topics. So, I'm trying to build a model of a a Chevy Kodiak or GMC Topkick (essentially the same vehicle I'm led to believe?). This photo was my main inspiration: http://www.frankscustom.com/images/IMG_1737.JPG (watch out it's pretty large)I'd like the built the crew-cab version, with the 19.5" wheels/tires as seen in the pic. Having never built a truck model in my life, but armed with some scratchbuilding experience on aircraft and armor models I think I should be able to tackle this project. However, I am having some trouble getting dimensions/drawings of said vehicle and also finding possible donor kits/aftermarket parts. Any leads are appreciated, again, I'm totally new at truck modeling -Anthony
Jim B Posted March 23, 2010 Posted March 23, 2010 (edited) For this GMC, you could go with the All Season's Collectable Toys GMC Topkick which is a 1999: http://sourkrautsmodeltrucks.com/?page_id=3&category=2&product_id=28. Here's his crew cab version: http://sourkrautsmodeltrucks.com/?page_id=3&category=2&product_id=536. Plaskit makes a hood conversion: http://sourkrautsmodeltrucks.com/?page_id=3&category=6&product_id=84 Daniel makes good stuff. You can get a hold of him at plaskit_resin@yahoo.ca As for a base kit: you'll need an AMT Chevy Silverado kit AND an AMT Ford LN8000 kit. Lo-Pro tires couldn't hurt either. http://sourkrautsmodeltrucks.com/?page_id=3&category=9&product_id=109 As for an engine, well you'll have to modify the one in the Silverado kit as there are currently no resin Class 5 engines available. I think the Caterpiller 3208 from the Ford LN8000 kit will be too big. You need a Cheyy Big Block V-8. Hope this helps. Edited March 23, 2010 by Jim B
Blake Rogers Posted March 23, 2010 Posted March 23, 2010 what i don't under stand is the small rims/wheels used on the 1:1's?
awan Posted March 23, 2010 Author Posted March 23, 2010 what i don't under stand is the small rims/wheels used on the 1:1's? Personally, I love the look of the smaller wheels, but I have no idea why they use them on the 1:1 trucks.
chuckyr Posted March 24, 2010 Posted March 24, 2010 http://s429.photobucket.com/albums/qq13/danielgailloux/GMC_Topkick/
rollinoldskoo Posted March 24, 2010 Posted March 24, 2010 the resin mentioned above is more like this one i made.... the newer ones are a different body
Sergey Posted March 24, 2010 Posted March 24, 2010 the resin mentioned above is more like this one i made.... the newer ones are a different body Very Impressive Pick Up, although it has many inaccuracys: GMC badge on the grill and "Chevrolet" on the rear gate. 22,5' wheels & uder Cab fuel tank with Pick Up body is quite a custom. Have you used PickUp bed from Silverado?
awan Posted March 25, 2010 Author Posted March 25, 2010 Impressive builds guys! Thanks for sharing. Does anyone have access to three-view drawings or any dimensions in general of the newer model Kodiaks and Topkicks? Someone shared a few 'body-builder' PDF links in my International 4400 thread..was hoping maybe there'd be something similar for the Topkick/Kodiak. -Awan
Jim B Posted March 25, 2010 Posted March 25, 2010 Did you look here: http://eogld.ecomm.gm.com/NASApp/mediumduty/gmmd_home.jsp Looks like it has just about everything you need.
rollinoldskoo Posted March 25, 2010 Posted March 25, 2010 Very Impressive Pick Up, although it has many inaccuracys: GMC badge on the grill and "Chevrolet" on the rear gate. 22,5' wheels & uder Cab fuel tank with Pick Up body is quite a custom. Have you used PickUp bed from Silverado? slow down with your comments man..... this is a model of a 90's topkick..... do some homework and check the links posted... sauerkraut has the same style body style posted.... and the tailgate? dude its a sticker.... and who really cares that much besides an IPMS show?
Sergey Posted March 25, 2010 Posted March 25, 2010 (edited) slow down with your comments man..... this is a model of a 90's topkick..... do some homework and check the links posted... sauerkraut has the same style body style posted.... and the tailgate? dude its a sticker.... and who really cares that much besides an IPMS show? O-Key, my mistake. Peace. Can you share some pictures of the prototype (the real PickUp) for your model? I'm collecting the information to build my own 90's Top kick using Perry's Resin Cab: http://www.perrysresin.com/catalog/pics/p_topkick.jpg Edited March 25, 2010 by Sergey
awan Posted March 26, 2010 Author Posted March 26, 2010 Did you look here: http://eogld.ecomm.gm.com/NASApp/mediumduty/gmmd_home.jsp Looks like it has just about everything you need. Perfect! I printed off some spec sheets...and I've got a couple of good hi-res top/side/front/back view shots that I've been measuring and scaling to size. Thanks for the link!
Rob Hall Posted March 26, 2010 Posted March 26, 2010 (edited) Those older ones have a totally different cab than the '03-09 models, though. The '93-02 Topkick/Kodiak cab is based on the '88-98 Silverado style cab, while the '03-09 are based on the full size van (Savanna/Express). I'd love to have in 1:25th the 'Ironhide' Topkick from the Transformers movie. Edited March 26, 2010 by Rob Hall
awan Posted March 26, 2010 Author Posted March 26, 2010 Those older ones have a totally different cab than the '03-09 models, though. The '93-02 Topkick/Kodiak cab is based on the '88-98 Silverado style cab, while the '03-09 are based on the full size van (Savanna/Express). I'd love to have in 1:25th the 'Ironhide' Topkick from the Transformers movie. I'm after the 2003-2010 cab design...I may actually end up scratchbuilding...just because the cab available is somewhat pricey for something I'm going to be chopping up. I will however buy most details aftermarket...but I supposed scratchbuilding truck components is much easier than aircraft components...so I should be ok. I've got a bunch of drawings and photos so I think I've got it covered. Just bought a huge stock of Evergreen plastics online..so I can get started as soon as they show up.
Sergey Posted March 27, 2010 Posted March 27, 2010 (edited) I'm after the 2003-2010 cab design...I may actually end up scratchbuilding...just because the cab available is somewhat pricey for something I'm going to be chopping up. I will however buy most details aftermarket...but I supposed scratchbuilding truck components is much easier than aircraft components...so I should be ok. I've got a bunch of drawings and photos so I think I've got it covered. Just bought a huge stock of Evergreen plastics online..so I can get started as soon as they show up. O, I will follow the rpoces. I plan to scratchbild "Ironhide"/TopKick too (after Custombilt 379 & Paulie Houling's "Love Mashine"). Good luck. Edited March 27, 2010 by Sergey
awan Posted March 28, 2010 Author Posted March 28, 2010 As for an engine, well you'll have to modify the one in the Silverado kit as there are currently no resin Class 5 engines available. I think the Caterpiller 3208 from the Ford LN8000 kit will be too big. You need a Cheyy Big Block V-8. In terms of an engine...will this work? http://cgi.ebay.com/PHOENIX-1-24-PTX-MINI-ENGINE-VEHEVY-V8-SS-454-BIG-BLOCK_W0QQitemZ110447328417QQcmdZViewItemQQptZLH_DefaultDomain_0?hash=item19b72c7ca1
awan Posted March 31, 2010 Author Posted March 31, 2010 (edited) As for a base kit: you'll need an AMT Chevy Silverado kit AND an AMT Ford LN8000 kit. By Ford LN8000..do you mean this? http://images32.fotki.com/v1064/photos/1/117425/3710160/31941_AMT_Ford_Louisville125-vi.jpg Also, if I've found the Chevy engine on Ebay, do I still need the Silverado? Also, I just got my order of Evergreen sheet/stock today..ordered a couple of the "Odds & Ends" bulk packs along with tube and sheet assortment sets so I should be pretty good to get started scratchbuilding whenever I find a Ford kit for a chassis to mess with. (Any chance that someone here has a parts kit sitting around I could get off you for a good price?) -Awan Edited March 31, 2010 by awan
Jim B Posted March 31, 2010 Posted March 31, 2010 Yes, that's the Ford LN8000 I was talking about. As for the Silverado, yes, you'll still need that kit, too. I think you used the engine & interior from that kit. If you go with the Plaskit hood, you'll need the cab from it as well.
awan Posted April 2, 2010 Author Posted April 2, 2010 Yes, that's the Ford LN8000 I was talking about. As for the Silverado, yes, you'll still need that kit, too. I think you used the engine & interior from that kit. If you go with the Plaskit hood, you'll need the cab from it as well. Alright. Do you have a picture of the Silverado kit I'm looking for?
Jim B Posted April 2, 2010 Posted April 2, 2010 No, sorry, I don't. But i would guess that anyn of the AMT Silverado kits would do as you're just going to take the cab & interior from it.
rollinoldskoo Posted April 24, 2010 Posted April 24, 2010 you need the DG productions van for the right cab.....
